LONG RANGE IP LINK
The StormCOMM is a complete UAS BLOS communication system, designed and manufactured by UAVision, tested and used by the Portuguese Air Force and Navy, that features the following capabilities:
-
Gyrostabilized Directional Antenna suitable for land and sea mobile GCS
-
LOS IP link up to 100KM range (150Km version in progress)
-
Ground segment IP tracker System (GPS and ADSB)
-
Integrated high performance 15 dB panel antenna
-
Bandwidth up to 20Mbps (6Mbps @100Km)
-
Frequency 2300 to 2700 MHz* OFDM modulation
-
AES Data encryption
![WhatsApp Image 2021-08-05 at 14.18.56 (2).jpeg](https://static.wixstatic.com/media/1635af_2dcd0ef1c4d04c7e8edf05dc8a1d53f2~mv2.jpeg/v1/fill/w_383,h_285,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/WhatsApp%20Image%202021-08-05%20at%2014_18_56%20(2).jpeg)
![](https://static.wixstatic.com/media/1635af_39b00a1d0f31426b88d50a06c2fca216~mv2.png/v1/fill/w_320,h_320,q_90/1635af_39b00a1d0f31426b88d50a06c2fca216~mv2.png)
![](https://static.wixstatic.com/media/1635af_7878ddc16aa14a34a72b9309b77a6b62~mv2.jpg/v1/fill/w_282,h_219,q_90/1635af_7878ddc16aa14a34a72b9309b77a6b62~mv2.jpg)
![](https://static.wixstatic.com/media/1635af_4d61ecaba8e040eb86b1fecb263a5c6e~mv2.png/v1/fill/w_320,h_320,q_90/1635af_4d61ecaba8e040eb86b1fecb263a5c6e~mv2.png)
![WhatsApp Image 2021-08-05 at 14.32_edited.jpg](https://static.wixstatic.com/media/1635af_692e2939d55546b2a9592eda8c5d4e0c~mv2.jpg/v1/crop/x_0,y_17,w_964,h_711/fill/w_386,h_285,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/WhatsApp%20Image%202021-08-05%20at%2014_32_edited.jpg)
StormCOMM systems range can be easily expanded by connecting multiple antennas through an IP Link. Command centers can be centralised only needing an IP.:
-
WEB interface for configuring & monitoring
-
Spectrum analyser for monitoring and adjustment
-
High precision servo system and mechanical system
-
180 Degrees continuous azimuth and -90 to +90 Degrees elevation
-
Ethernet 10/100 Mbps connector
-
Power requirements 28VDC 30W UAS 100W ground
-
High quality ruggedized tripod
-
IP67
